!ORIENTATION

Definition of local coordinate system

Parameter

NAME = Name of local coordinate system
DEFINITION = COORDINATES (Default)/NODES

2nd Line of later

• In case of DEFINITION=COORDINATES

(2nd line or later) a1, a2, a3, b1, b2, b3, c1, c2, c3

• In case of DEFINITION=NODES

(2nd line or later) a, b, c

Parameter Name	Attributions	Contents
a1, a2, a3	R	coordinate of point a
b1, b2, b3	R	coordinate of point b
c1, c2, c3	R	coordinate of point c
a,b,c	I	Node ID of a,b,c, respectively
